Technical catalogue
NEONFLEX 1515 SB is a flexible linear profile in 100% food-grade extruded silicone, with an integrated low-voltage LED source and a 15 × 15 mm square section. The front emitting surface (effective width ≥ 6 mm) produces a continuous line of light with no dot effect and a 120° beam angle. The SB (Side Bend) version is designed for lateral bending, left and right: it can follow planar profiles, frames, lettering and horizontal geometries while keeping the emitting surface always facing the observer. Vertical bending is not permitted.
Silicone LED Neon Flex · 15×15 mm · side bend · IP67
| LED density | 120 LED/m |
|---|---|
| Power | 8 – 20 W/m |
| Luminous efficacy | 40 – 60 lm/W |
| Beam angle | 120° |
| CCT | 2700K / 3000K / 4000K / 6500K |
| Ingress protection | IP67 |
| Section | 15 × 15 mm |
| Power supply | 12 VDC / 24 VDC (SELV) |
| Minimum bending diameter | 100 mm |
