Technical catalogue
Professional backlit LED panel, recessed or surface-mounted, for offices, retail, commercial environments and healthcare facilities. Main size 60×60 cm (30W, 4800 lm, 160 lm/W, UGR 22, 4000K, uniform diffuser) with range extensions 120×30 and 120×60 cm. Formerly the I-PAN BK series, evolved into the new ALTAVIA Pannel brand architecture.
Backlit LED panel · 60×60 · 30W · 4800 lm · 160 lm/W
| Power | 25-36 W |
|---|---|
| Luminous flux | fino a 4.800 lm |
| LED efficacy | 160 lm/W |
| CCT | 4000K standard · 2200-5700K a richiesta |
| CRI | >80 |
| UGR | 22 |
| Ingress protection | IP20 |
| Service life | L70 >50.000h |
| Thickness | 30-33 mm |
| Material | SPCC + AL6063 + diffusore PS |
| Control | On/Off · DALI opzionale |
