Technical catalogue
SOLIS NEXT is an integrated solar LED road lighting luminaire: monocrystalline silicon photovoltaic panel, LiFePO4 battery, control electronics and SMD5050 LED modules in a single die-cast aluminium body. Available in the high-performance PRO configuration with MPPT controller and the balanced CORE configuration with PWM controller, each in the compact S and extended L sizes. Luminous flux ranges from 3.400 lm to 6.700 lm, with mechanical tilt up to 180°, dusk/dawn photosensor and timed management. Designed for main and secondary roads, squares, paths and areas without power supply cabling.
Integrated solar LED road lighting luminaire
| Photovoltaic panel power | 60 / 90 W |
|---|---|
| Conversion efficiency | 22 % |
| Battery | LiFePO4 3,2V 60 / 90 Ah |
| Battery energy | 192 / 288 Wh |
| Luminous flux | 3.400 - 6.700 lm |
| Light source | 80 / 160 LED SMD5050 |
| CRI | >70 |
| CCT | 3000 / 4000 / 5000 / 5700 / 6500 K |
| Charging time | circa 4 (con irraggiamento sufficiente) h |
| Autonomy in rainy weather | fino a 3 giorni |
| Ingress protection | IP65 |
| Body | Alluminio pressofuso, grigio |
| Mounting height | 4 - 7 m |
| Mounting | Su palo o su braccio, orientabile 180° |
| Warranty | 3 anni |
