Technical catalogue
PAD URBAN is a professional LED luminaire in the Lumeitalia range. The technical data shown below comes from the official product record.
Design ultra-sottile per arredo urbano
Circular LED luminaire with perimeter light signalling
P.A.D. Urban is the circular LED urban furniture luminaire with eight independent optical modules, rotationally symmetric distribution and an adjustable Z-OTP system. The polycarbonate perimeter frame integrates Lume.Sign® and Kromo Light System® for signalling and colour scenes; Lume-Fi® enables IoT management, geolocation and remote control. It is designed for post top installation on Ø48/60 mm poles in parks, squares and pedestrian areas.
| Power | 10-80 W |
|---|---|
| CCT | 2700-6500 K |
| CRI | 70/80/90 |
| Ingress protection | IP66 / IK09 |
| System efficacy | 159 lm/W |
| LED source efficacy | >230 lm/W |
| Optic | Z-OTP regolabile |
| Control | Lume-Fi / Lume.Sign / Kromo Light System |
| Dimensions | Ø430 × H159 × sp.55,2 mm |
| Mounting | Cimapalo Ø48/60 mm |
